LED Mesh Screen Easy to install small spacing transparent flexible long-distance power supply LED grid screen
Application scenarios
1. Building facade and landmark landscape
Used to create dynamic display curtain walls, such as commercial buildings and urban landmarks, combined with
dynamic lighting effects to enhance visual impact.
2. Commercial Advertising and Media Communication
Using public places such as shopping malls and squares as advertising carriers to attract consumers
and increase brand exposure. three Transportation and Sports Venues
Used for dynamic information dissemination at stations, airports, and sports events, combining aesthetics and functionality.
four Performing Arts and Urban Beautification
Enhance the atmosphere through dynamic content in performing arts venues or urban festival events.
3, The global outdoor LED display market continues to grow, with sales reaching 2.404 billion US dollars in 2023 and expected to increase to
4.358 billion US dollars by 2030, with a compound annual growth rate of 9.0%. As a niche field, XQD photoelectric grid screen has a strong demand
for innovative design in high-end applications, especially in landmark buildings and creative advertising, with enormous potential.
2020 square point light mesh screen application instructions
| Product basic parameters | |
| Item | H2020 square project mesh screen |
| Specifications | P40 | P80 | P120 |
| Application | Indoor/outdoor | Indoor/outdoor | Indoor/outdoor |
| Installation | steel structure support | steel structure support | steel structure support |
| Load wire | 2.0mmWire fixing (Single module 2pcs) |
| Single module width | 0.4 m/pcs | 0.4 m/pcs | 0.4 m/pcs |
| Max length of single row | 8m | 12m | 18m |
| No. of lights per SQM | 625led/m2 | 156led/m2 | 69led/m2 |
| Power per SQM | 375W/sqm | 94W/sqm | 42W/sqm |
| Per SQM weight | 6KG/sqm | 2.1KG/sqm | 1.5KG/sqm |
| Lamp flatness | < 1mm | < 1mm | < 1mm |
| Viewing distance | >20m | >40m | >60m |
| Viewing angle | Within 140° | Within 140° | Within 140° |
| Signal transmission distance | Super Category 5 network cable up to 90m |
| Display mode | Computer/master synchronization |
| Overall transparency | 56% | 78% | 89% |
Applications:
Widely used in billboards, highways, railway tunnels, bridges, squares, stadiums, trees, parking lots,
building walls, hotel, meeting room, offices , hospital , schools , factories , commercial lighting ,
shopping malls, supermarkets, kitchen, display, backlight and so on.
Park square and science and technology exhibition hall: The flexible and customized design of the grid screen enables it to cooperate with different shapes and architectural surfaces, and achieve creative lighting effects in the park square and science and technology exhibition hall and other places, such as somosensory interaction, infrared induction, lighting scene interaction, etc.
|
|
